Embed Views in Nodes

Nodes in Panel-ReactFlow can display more than a text label. By passing a Panel component as the view parameter, you can embed any Panel viewable directly inside a node — a Markdown summary, a chart, an image, an interactive widget, or even a complete mini-dashboard.

Views are rendered server-side with Bokeh and streamed into the React Flow canvas, so they have the same interactivity and update behaviour as any other Panel component. This is ideal for at-a-glance previews: show a sparkline on a data-source node, a status badge on a pipeline step, or a thumbnail on an image-processing node.

Screenshot: nodes with embedded Panel views showing charts and markdown

Complete runnable example

This script is a minimal, working example that produces the visualization shown above.

import panel as pn

from panel_reactflow import ReactFlow

pn.extension("jsoneditor")

nodes = [
    {
        "id": "source",
        "type": "panel",
        "label": "Data Source",
        "position": {"x": 0, "y": 0},
        "data": {},
        "view": pn.pane.Markdown("**Status:** connected\n\nRows: 1,204 • Updated 3s ago"),
    },
    {
        "id": "metric",
        "type": "panel",
        "label": "KPI",
        "position": {"x": 320, "y": 0},
        "data": {},
        "view": pn.indicators.Number(
            value=87.3,
            name="Accuracy",
            format="{value}%",
            colors=[(90, "orange"), (100, "green")],
        ),
    },
    {
        "id": "output",
        "type": "panel",
        "label": "Output",
        "position": {"x": 160, "y": 180},
        "data": {},
        "view": pn.pane.HTML(
            "<div style='padding:6px;font-size:12px;color:#475569;'>✅ Pipeline healthy</div>"
        ),
    },
]

edges = [
    {"id": "e1", "source": "source", "target": "metric"},
    {"id": "e2", "source": "metric", "target": "output"},
]

flow = ReactFlow(
    nodes=nodes,
    edges=edges,
    sizing_mode="stretch_both",
)

pn.Column(flow, sizing_mode="stretch_both").servable()

How this code maps to the visualization

  • Each node has a different view (Markdown, Number, HTML).
  • Those views are rendered inline inside the three visible nodes.
  • edges creates the two visible connections between those nodes.

Add a view to a node

Set the view key when defining a node. The value can be any Panel Viewable — a pane, a widget, a layout, or a custom component.

import panel as pn
from panel_reactflow import ReactFlow

nodes = [
    {
        "id": "source",
        "type": "panel",
        "label": "Data Source",
        "position": {"x": 0, "y": 0},
        "data": {},
        "view": pn.pane.Markdown("**Status:** connected"),
    },
    {
        "id": "chart",
        "type": "panel",
        "label": "Preview",
        "position": {"x": 300, "y": 0},
        "data": {},
        "view": pn.pane.Matplotlib(fig, tight=True),
    },
]

flow = ReactFlow(nodes=nodes, edges=[], sizing_mode="stretch_both")

Add a view when adding a node at runtime

Pass a NodeSpec with a view to add_node():

from panel_reactflow import NodeSpec

flow.add_node(NodeSpec(
    id="live",
    label="Live Feed",
    position={"x": 600, "y": 0},
    view=pn.indicators.Number(value=42, name="Metric"),
))

Use interactive widgets as views

Because views are full Panel components, you can embed interactive widgets and wire them up with callbacks:

import panel_material_ui as pmui

toggle = pmui.Switch(value=True, label="Enabled")
toggle.param.watch(
    lambda e: flow.patch_node_data("ctrl", {"enabled": e.new}),
    "value",
)

nodes = [
    {
        "id": "ctrl",
        "type": "panel",
        "label": "Controller",
        "position": {"x": 0, "y": 0},
        "data": {"enabled": True},
        "view": toggle,
    },
]

Views vs. editors

Views and editors serve different purposes:

Views Editors
Where Rendered inside the node on the canvas. Rendered in a side/toolbar/node panel.
When Always visible. Shown when the node or edge is selected.
Purpose At-a-glance display, inline controls. Detailed data editing.
Scope Nodes only. Nodes and edges.

You can use both on the same node — for example, a sparkline view inside the node and a full form editor in the side panel.

Tips

  • Keep views compact. Large views push nodes apart and clutter the canvas.
  • Views update reactively. If your view is backed by a reactive data source (e.g. a streaming DataFrame), it will refresh automatically.
  • For read-only previews, pn.pane.Markdown, pn.pane.HTML, and pn.indicators.* are lightweight choices.
